At Industrial Parts and Components, our Y-Type Strainers are engineered to provide essential protection for your piping systems by mechanically removing solids from flowing liquids, gases, or steam. Acting as a critical safeguard, these strainers capture debris such as scale, rust, and jointing compound, preventing damage to expensive downstream equipment like pumps, control valves, and flow meters. With a compact, "Y" shaped design, they offer an economical and versatile solution for maintaining fluid purity without requiring significant space

Key Features

• High-Strength Perforated Screens:Equipped with precision-engineered stainless steel meshes or perforated sheets designed to withstand high differential pressures while ensuring maximum debris retention.
• Blow-Off Capability:Features a threaded or flanged "blow-off" port in the strainer cap, allowing for easy cleaning of the basket and removal of accumulated debris without interrupting the main flow
• Streamlined Flow Path:The angled body design is optimized to minimize turbulence and pressure drop, ensuring that system efficiency is maintained even as the screen begins to fill.

Specification Table

Parameter	Details
Body Material	Cast Iron, Ductile Iron, Carbon Steel, or Stainless Steel
Screen Material	304/316 Stainless Steel (Perforated or Wire Mesh)
Filtration Range	20 mesh (900 microns) to 400 mesh (37 microns)
Pressure Ratings	ANSI Class 150, 300, 600 / PN16 to PN64
Connection Types	Threaded (NPT/BSP), Socket Weld, or Flanged
